Features HIKMICRO THUNDER ZOOM 2.0 THERMAL SCOPE

Hikmicro Thunder Zoom 2.0 Thermal Scope

The Thunder TH50Z 2.0 thermal scope has Optical Zoom and a 20mK thermal sensor with 384 x 288 resolution. This device is the perfect combination to use both in forested areas with abundant vegetation and also in open fields. In addition, its F0.8 large aperture can strengthen the ability to view objects.

The Thunder TQ60Z 2.0 thermal scope has Optical Zoom and a 20mK thermal sensor with 640 x 512 resolution. This device is the perfect combination to use both in forested areas with abundant vegetation and also in open fields. In addition, it has a 60 mm lens with a large aperture of F1.1 and a maximum detection range of 3,000 meters.

Main features

Thunder Zoom TH50Z 2.0

384 × 288 resolution with 12 μm detector
NETD high sensitivity thermal module < 20 mK (25 °C, F# = 1.0)
Dual field of view of 25mm (F0.8) and 50mm (F1.0) lenses
0.39-inch OLED display with 1024 × 768 resolution
Up to 6.5 hours of continuous operation
Replaceable and rechargeable lithium-ion battery packs
High shock resistance up to 1000 g/0.4 ms
Detection range up to 2,600 m
Image Sensor: 384 × 288 Uncooled Focal Plane Arrays
Pixel interval: 12μm
Lens: 50mm
NETD: Less than 20 mK (@25°C), F# = 1.0
Magnifications: 2.2x to 17.4x/4.3x to 34.6x (8x)
Minimum focusing distance: 25mm: 4m/50mm: 10m
Field of view: 10.5° × 7.9°/18.4 m × 13.8 m; 5.3° × 4°/9.2m × 6.9m
Screen: OLED, 1024 × 768
Color palettes: Bright black, bright white, bright red, fusion
Focus: Optical zoom, focus ring
Exit pupil: 6mm
Eye relief: 45mm
Detection range: 2,600 meters
Storage: Built-in memory module (16 GB) Yes
Video recording: Yes
Audio recording: Yes
Capture snapshot image: Yes
Reverse Trigger Recording: Yes
Maximum recoil: 1,000 g / 0.4 ms
Brightness adjustment: Yes
Tone adjustment: Yes
Distance meter: Yes
Wi-Fi: Yes
Standby mode: Yes
Battery Type: Replaceable and rechargeable lithium battery
Run time: Up to 6.5 hours of continuous operation
Protection: IP67
Working temperature: From -30°C to 55°C
Dimensions: 241.2mm × 67mm × 73.4mm
Weight: 750 gr (without battery)
Warranty: 36 months
Sensor warranty: 10 years

*Does not include rail to mount on the weapon.

Thunder Zoom TQ60Z 2.0

Main features

640 × 512 resolution with 12 μm detector
NETD high sensitivity thermal module < 20 mK (25 °C, F# = 1.0)
Dual FOV of 35mm (F0.9) and 60mm (F1.1) lenses
0.39-inch OLED display with 1024 × 768 resolution
Up to 6.5 hours of continuous operation
Replaceable and rechargeable lithium-ion battery packs
High shock resistance up to 1000 g/0.4 ms
Detection range up to 3,000 m
Image Sensor: 640 × 512 Uncooled Focal Plane Arrays
Pixel interval: 12μm
Lens: 60mm
NETD: Less than 20 mK (@25°C), F# = 1.0
Magnifications: 1.8x to 14.6x/3.1x to 25.0x (8x)
Minimum focusing distance: 35mm: 7m/60mm: 9m
Field of view: 12.5° × 10°/21.9 m × 17.6 m; 7.3° × 5.9°/12.8m × 10.2m
Screen: OLED, 1024 × 768
Color palettes: Bright black, bright white, bright red, fusion
Focus: Optical zoom, focus ring
Exit pupil: 6mm
Eye relief: 45mm
Detection range: 3,000 meters
Storage: Built-in memory module (16 GB) Yes
Video recording: Yes
Audio recording: Yes
Capture snapshot image: Yes
Reverse Trigger Recording: Yes
Maximum recoil: 1,000 g / 0.4 ms
Brightness adjustment: Yes
Tone adjustment: Yes
Distance meter: Yes
Wi-Fi: Yes
Standby mode: Yes
Battery Type: Replaceable and rechargeable lithium battery
Run time: Up to 6.5 hours of continuous operation
Protection: IP67
Working temperature: From -30°C to 55°C
Dimensions: 254.4mm × 68.5mm × 80.6mm
Weight: 843 gr (without battery)
Warranty: 36 months
Sensor warranty: 10 years

*Does not include rail to mount on the weapon.
